Name: High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans
Brand: SHANGHAI QUANYE METAL PACKAGING MATERIALS CO.,LTD
SKU: TFS DR8
Price: 499.01 USD
Availability: InStock

Maison > produits > Bobine de fer-blanc >

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans

Lieu d'origine:

Chine

Nom de marque:

QuanJiang

Certification:

SGS, Mill certificate

Numéro de modèle:

TFS DR8

Contactez-nous

Demandez une citation

Détails de produit

Matériel::

Mr, SPCC, Prime Tinplate / TFS

Dureté::

TS230, TS245, TS260, TS275, TS290, TH415, TH435, TH520, TH550, TH580, TH620

Taper::

bobine et feuille

Caractère::

T1, T2, T3, T4, T5, DR8, DR7, DR9

Épaisseur::

0.15-0.5mm

Revêtement en étain::

1.1/1.1, 2.0/2.0, 2.8/2.8, 5.6/5.6, etc. ou personnalisé

Impression::

Impression compensée dans CYMK / PMS selon vos illustrations

Largeur:

600-1000mm ou personnalisé

Longueur:

600mm-1200mm ou en tant que bobines

Application::

boîte de lait, boîte aérosol, boîte de sardines, boîte de thon, boîte de vergetabl, boîte de peintur

Conditions de paiement et d'expédition

Quantité de commande min

25 tonnes

Prix

Negotiated

Détails d'emballage

Norme de mer avec palette en bois, coin protégée. par feuille ou bobinages selon le client l'exi

Délai de livraison

Négocié

Conditions de paiement

T/T

Capacité d'approvisionnement

50000mt / mois

PRODUITS CONNEXES

Vidéo

High-Strength Electrolytic Tin Plate for Packaging Box - TH415 to TH620 Hardness 0.2mm

Obtenez le meilleur prix

Vidéo

High-Strength Electrolytic Tin Plate Coils with Bulk Inventory - TH435/TH520/TS260/TS290 Grades

Obtenez le meilleur prix

Vidéo

Industrial Grade Electrolytic Tin Plate for Oil, Grease, Paint & Polish Packaging Containers

Obtenez le meilleur prix

Premium Electrolytic Tin Plate Sheets & Coils for Food Cans, Aerosol Containers, and Paint Packaging

Obtenez le meilleur prix

Contactez-nous

+8618321408860-021-56922400

quanye@spte.cn

+86-021-56922411

Contact maintenant

Description de produit

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans

Product Description:
Electrolytic Tin Plate (ETP) and Tin Free Steel (TFS) represent advanced packaging materials engineered for superior performance in food and industrial applications. Our TFS DR9 tinplate coils feature exceptional high-strength characteristics with hardness grades ranging from TH415 to TH620, providing manufacturers with versatile solutions for demanding packaging requirements. These materials utilize an electrolytic chromium coating that offers superior paint adhesion and excellent sulfide stain resistance, making them particularly suitable for protein-rich food products like fish and meat. The DR9 temper designation ensures optimal strength and formability, while the chromium coating provides exceptional corrosion resistance without using tin, creating a cost-effective and environmentally friendly packaging solution.

Features & Advantages:

Superior paint adhesion properties for enhanced decoration and branding
Excellent sulfide stain resistance for protein-rich food packaging
High-temperature resistance maintains integrity during sterilization processes
Exceptional alkali resistance for diverse product compatibility
Environmentally friendly chromium coating solution
Excellent formability and weldability for efficient manufacturing
Multiple hardness grades accommodate various strength requirements
Cost-effective alternative to traditional tinplate materials

Applications:

Food cans for fish, meat, and protein-rich products
Aerosol containers and chemical packaging
Paint and industrial compound containers
Beverage can ends and closures
Pharmaceutical and specialty packaging

Technical Parameters:

Property	Specifications
Material Type	TFS (Tin Free Steel), Electrolytic Tin Plate
Thickness Range	0.15-0.5mm
Available Widths	660-1090mm
Hardness Grades	TH415, TH435, TH520, TH550, TH580, TH620
Surface Finish	Bright, Stone, Silver, Matte
Coating Options	1.1/1.1 to 5.6/5.6 g/m² (customizable)
Temper Grades	DR9, T1-T5, DR7-DR9
Standards	JIS G3303 Certified

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans 0

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans 1

Workshop Show

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans 3

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans 4

Production Process

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans 5

PARTNER

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans 6

High-Strength TFS DR9 Tinplate Coils - TH415 to TH620 Hardness Grades for Food Cans 7

FAQ:

What are the main advantages of TFS over traditional tinplate?
TFS offers superior paint adhesion, excellent sulfide resistance, and cost-effectiveness while maintaining similar corrosion protection properties.
How quickly can I get price information?
We typically provide quotations within 24 hours of receiving your inquiry, excluding weekends and holidays.
Can I order samples before placing a bulk order?
Yes, we welcome sample orders and can provide material samples for your testing and evaluation.
What is your standard lead time for production?
Lead times vary by order quantity, typically 7-15 days for smaller quantities and up to 30 days for larger production runs.
What payment terms do you accept?
We primarily accept T/T payments, though terms are negotiable based on order size and customer relationship.
